      Hanwha SMT Machine
      Name:Hanwha Pick and Place Machine Vision
      Model:Hanwha Pick and Place Machine Vision
      Brief:

      Hanwha Pick and Place Machine Vision,Hanwha utilizes upward looking vision inspection of all parts on all spindles; downward looking vision inspection of fiducials including implied (holes, pads, silkscreen, etc.). Each placement spindle utilizes an integrated HD/mega- pixel head camera (six per head) with integrated high performance multi-stage illumination for high resolution vision inspection and alignment of 01005 chips to components as large are 23mm(L) x 23mm(W) x 15mm(H). For components requiring a larger field of view,

      Content

      Hanwha Pick and Place Machine Vision Recognition of Components and PCBs

      Hanwha utilizes upward looking vision inspection of all parts on all spindles; downward looking vision inspection of fiducials including implied (holes, pads, silkscreen, etc.). Each placement spindle utilizes an integrated HD/mega- pixel head camera (six per head) with integrated high performance multi-stage illumination for high resolution vision inspection and alignment of 01005 chips to components as large are 23mm(L) x 23mm(W) x 15mm(H). For components requiring a larger field of view,

      FIDUCIAL VISION

      STAGE VISION

      Hanwha stage (or stationary) camera is used
      for large ICs and/or SMT connectors up to 72mm in length; polygon recognition can also be utilized when auto- teaching odd-form components is required. Samsung’s fiducial recognition system is equally powerful with integrated multi-stage illumination for reliable recognition of various fiducial types, and placement angle preview capability for look-down drawing of component outlines including leads for pre-placement verification.

      Hanwha SMT Assembly Line

      smt printer+smt mounter + conveyor + reflow oven. length is 9.949m Hanwha SM471 Plus Placement Pick and Place Machine



      Hanwha SM471 plus placement pick and place machine for Hanhwa SMT Production line. SM471 plus placement speed up to 78,000 CPH, feeder inputs 120 PCS.
